63 Slide Friction PU Tennis Flooring With Silicon Buffer Layer And Concrete Base

JiangSu ChangNuo New Materials Co., Ltd.
Contact Now

63 Slide Friction PU Tennis Flooring With Silicon Buffer Layer And Concrete Base

  • 1
  • 2
  • 3

Brand Name : CN Sports

Model Number : CN-S02

Certification : ITF/RoHS/ISO140019001/ISO14001/ISSS

Place of Origin : China

MOQ : /

Price : US$10-35/square meter

Payment Terms : L/C, T/T

Supply Ability : 100000Tons per year

Delivery Time : Within 15 work days after your deposit

Packaging Details : Pack in barrel/pallet

Material : Silicon Polyurea

Application : outdoor school stadiums and Gymnasiums

Color : Red or you can customize

Warranty : 5 Years

Function : anti-seepage,waterproof and high rebound ,anti-uv

Slid Friction : 75

Impact Absorption : 7

Value of Reboubnd : 84

Contact Now

CN-S02 Silicon TB-002 Buffer Layer and Concrete Base 63 Slid Fricton PU Tennis Flooring

Product Description


About Tennis Court

SPU acrylic tennis court system uses modified tenacious acrylic resin as the abrasion resistant layer. It’s a
breakthrough for the brittleness and fissility shortcomings of the traditional acrylic material.
Polymer compound material supports the surface layer well and its excellent ductility plays an effective role in
dynamic anti-crack performance.


Then it combines with the permeation-type primer to form an integral rebound structure that has high
adhesion and weatherability.


The prime coat isolates moisture underground and the layer has effective anti-seepage. Thus, all these
ensure the floor durable.

The launch of SPU Tennis Court System is a complement to the shortcoming of the hard acrylic tennis court.
Especially the sport protection which is provided by its resilience, it solves the sport harm to the athletes
caused by the hard ground. At the same time, it further makes the ground provide more professional sport
feeling for matches.


To promote the sport profession and protection advantage of the traditional acrylic floor
To improve the weakness of the traditional acrylic floor, durable and professional.
The quality of the production is validated by international events and it is qualified by the State Administration
of Environment Protection's product certification.

Sports Performance Data

NO. items index of standard results
1 value of rebound, % ≥ 80 88
2 impact absorption, % 5~15 9
3 Slid friction, N 60~100 76
4 Water permeability, mm/min 0 0

Pysical Properties Data

NO. items index of standard results
1 Elongation at break, % ≥ 400 857
2 tensile strength, MPa ≥ 1.8 3.2
3 artificial weathering ageing resistance d(300h)

No bubble, no peeling, no crack;

Powder ≤ 1 grade, △ E ≤ 5.0

No bubble, no peeling, no

crack; Powder ≤ 1 grade,

△ E=0.9

4 Elongation at break, % ≥ 300 858
5 tensile strength, MPa ≥ 1.3 1.6
6 wearability(750g/500r)/g ≤ 0.050 0.035
7 water resistance

No bubble, no peeling, allows slight

discoloration, recover after 2h

No bubble, no peeling, no

discoloration

8 Flame retardancy, class I I

63 Slide Friction PU Tennis Flooring With Silicon Buffer Layer And Concrete Base

63 Slide Friction PU Tennis Flooring With Silicon Buffer Layer And Concrete Base

Project Case

63 Slide Friction PU Tennis Flooring With Silicon Buffer Layer And Concrete Base

Package

63 Slide Friction PU Tennis Flooring With Silicon Buffer Layer And Concrete Base

Company Photo

63 Slide Friction PU Tennis Flooring With Silicon Buffer Layer And Concrete Base
