Brand Name : CN Sports
Model Number : CN-S02
Certification : ITF/RoHS/ISO140019001/ISO14001/ISSS
Place of Origin : China
MOQ : /
Price : US$10-35/square meter
Payment Terms : L/C, T/T
Supply Ability : 100000Tons per year
Delivery Time : Within 15 work days after your deposit
Packaging Details : Pack in barrel/pallet
Material : Silicon Polyurea
Application : outdoor school stadiums and Gymnasiums
Color : Red or you can customize
Warranty : 5 Years
Function : anti-seepage,waterproof and high rebound ,anti-uv
Slid Friction : 75
Impact Absorption : 7
Value of Reboubnd : 84
CN-S02 Silicon TB-002 Buffer Layer and Concrete Base 63 Slid Fricton PU Tennis Flooring
Product Description
About Tennis Court
SPU acrylic tennis court system uses modified tenacious acrylic resin as the abrasion resistant layer. It’s a
breakthrough for the brittleness and fissility shortcomings of the traditional acrylic material.
Polymer compound material supports the surface layer well and its excellent ductility plays an effective role in
dynamic anti-crack performance.
Then it combines with the permeation-type primer to form an integral rebound structure that has high
adhesion and weatherability.
The prime coat isolates moisture underground and the layer has effective anti-seepage. Thus, all these
ensure the floor durable.
The launch of SPU Tennis Court System is a complement to the shortcoming of the hard acrylic tennis court.
Especially the sport protection which is provided by its resilience, it solves the sport harm to the athletes
caused by the hard ground. At the same time, it further makes the ground provide more professional sport
feeling for matches.
To promote the sport profession and protection advantage of the traditional acrylic floor
To improve the weakness of the traditional acrylic floor, durable and professional.
The quality of the production is validated by international events and it is qualified by the State Administration
of Environment Protection's product certification.
Sports Performance Data
| NO. | items | index of standard | results |
| 1 | value of rebound, % | ≥ 80 | 88 |
| 2 | impact absorption, % | 5~15 | 9 |
| 3 | Slid friction, N | 60~100 | 76 |
| 4 | Water permeability, mm/min | 0 | 0 |
Pysical Properties Data
| NO. | items | index of standard | results | |
| 1 | Elongation at break, % | ≥ 400 | 857 | |
| 2 | tensile strength, MPa | ≥ 1.8 | 3.2 | |
| 3 | artificial weathering ageing resistance d(300h) | No bubble, no peeling, no crack; Powder ≤ 1 grade, △ E ≤ 5.0 | No bubble, no peeling, no crack; Powder ≤ 1 grade, △ E=0.9 | |
| 4 | Elongation at break, % | ≥ 300 | 858 | |
| 5 | tensile strength, MPa | ≥ 1.3 | 1.6 | |
| 6 | wearability(750g/500r)/g | ≤ 0.050 | 0.035 | |
| 7 | water resistance | No bubble, no peeling, allows slight discoloration, recover after 2h | No bubble, no peeling, no discoloration | |
| 8 | Flame retardancy, class | I | I |


Project Case
